Presonus Quantum HD8
The Quantum HD8 is a sound card offered by the brand Presonus. The PreSonus Quantum HD8 is equipped with eight MAX-HD microphone preamps, offering +75 dB of gain. This enhancement results in clearer and more detailed recording of vocals and instruments. These preamps ensure minimal noise level and exceptional clarity, which is crucial for capturing nuanced performances. With its advanced design, the Quantum HD8 promotes sonic purity, making it a standout feature for serious studio artists. This audio interface elevates the recording level of guitars and basses with its inputs, developed in partnership with renowned engineers at Fender. This collaboration has resulted in inputs that preserve the natural tone and resonance of your instrument, greatly enhancing recordings and live performances. Whether capturing a bass groove or a guitar riff, the quality is unmatched. Leave manual adjustments aside and focus on your performance with the Auto Gain function of the Quantum HD8. Simply press a button for the interface to calculate and automatically adjust the optimal gain for your microphones and instruments. This revolutionary function simplifies tasks for both beginners and experienced users, ensuring consistent, hassle-free, high-quality recordings. The preamplification outputs of the Quantum HD8 open up a vast sonic exploration terrain. Direct audio from your recording software to your guitar or bass amp, then re-record to test various amp settings, pedal effects, and microphone positions. This feature allows musicians to refine their sound and discover unique tonal combinations, making the Quantum HD8 an invaluable tool for sound creation.
The Strengths of the Quantum HD8
The Key Features of the Quantum HD8
MAX-HD Preamps for Exceptional Sound Quality
Fender Audio Interface for Guitars and Basses
Revolutionary Auto Gain Function of the Quantum HD8
Fully Utilize Your Sound with the Reamping Outputs of the Quantum HD8
Expert Reviews
Headphone outputs: 2
Connectivity: USB-C
Voltage: 220-240V EU
Phantom power: +48 VDC
Digital audio bit depth: 32-bit
Supported sampling rates: 44.1, 48, 88.2, 96, 176.4, 192 kHz
Digital audio dynamic range: 124 dB
Inputs:
Instrument inputs: 111 dB (A-Weighted, Minimum Gain)
Line inputs: 118 dB (A-Weighted, Minimum Gain)
Microphone preamp: 116 dB (A-Weighted, Minimum Gain)
Instrument inputs: 20 Hz to 20 kHz, +/- 0.1 dB (Unity Gain, 1 kHz Reference)
Line inputs: 20 Hz to 20 kHz, +/- 0.1 dB (Unity Gain, 1 kHz Reference)
Microphone preamp: 20 Hz to 20 kHz, +/- 0.1 dB (Unity Gain, 1 kHz Reference)
Instrument inputs: 75 dB
Line inputs: +/- 10 dB
Microphone preamp: 75 dB
Instrument inputs: +21 dBu (Unbalanced, Minimum Gain)
Line inputs: +18 dBu (Balanced, Minimum Gain)
Microphone preamp: +18 dBu (Balanced, Minimum Gain)
Line inputs: 0.001% (1 kHz, Minimum Gain)
Microphone preamp: 0.002% (1 kHz, Minimum Gain)
Outputs:
Headphone output dynamic range: 118 dB (A-Weighted)
Headphone output frequency response: 20 Hz to 20 kHz, +/- 0.3 dB (Unity Gain, 1 kHz Reference)
Headphone output impedance operating range: 33 Ohms
Maximum output of headphone outputs: 11 dBu (50 Ohms)
Line output connection type: Female TRS 1/4 inch
Main and line output dynamic range: 123 dB (A-Weighted)
Main and line output frequency response: 20 Hz to 20 kHz, +/- 0.2 dB (Unity Gain, 1 kHz Reference)
Maximum level of main and line outputs: +18 dBu (Balanced)
MIDI inputs/outputs: 5-pin DIN female
Word Clock input/output: BNC Connector, 4.5 Vpp @ 75Ω Load
Dimensions: 44 x 483 x 219 millimeters
Shipping weight: 2.93 kg
Comes with: DB-9 breakout cable (for MIDI and S/PDIF inputs/outputs), 1.5-meter USB-C to USB-C cable, IEC power cord
Euroguitar Reference : 110723
